X Series E83 X3 2.5Si (N52K) OFFRD
51 48 070
Removing and installing/replacing sound
insulation on left or right rear door
Special tools required:
•
00 9 317
Necessary preliminary tasks:
•
Remove rear door trim panel
Disconnect plug connection (1).
Unclip clip (2).
Using special tool 00 9 317 (trim panel wedge), lever out sealing
bead (3) of sound insulation (4) completely or if necessary
partially.
Feed wires (5) out of sound insulation (4).
Installation:
In case of replacement or partial detachments, lay butylene tape
(sourcing reference: BMW Parts Service) depending on the
conditions on inner door panel or sound insulation.
Seal cable penetrations with butylene tape.
RA Removing and installing/replacing sound insulation on left or right rear door
