X Series E83 X3 2.5Si (N52K) OFFRD
Carefully pull cover over mounts towards front.
Slide all cover lugs (1) in succession in direction of backrest
center (if necessary with cleaning wedge 00 9 323).
Installation:
Press tabs with special tool 00 9 323 into mounting on both
sides.
Grip lower cover (1) and padding and gently press clips (2)
together, pull out head restraint guide (3).
Remove cover and padding.
Installation:
Clips of head restraint guide (2) must not be damaged.
Replacement of backrest cover or padding only:
Pull cover out of padding.
Installation:
Feed cover lugs (1) into openings of padding (2). Make sure
piping (3) is resting in opening of padding (4).
RA Replacing backrest cover for right rear seat (through-loading system)
