X Series E83 X3 2.5Si (N52K) OFFRD
Press locking clip (1) and detach high-pressure line (2) from
spray nozzle for headlight washer system (4).
Pull out retainer (3) in direction of arrow.
Remove spray nozzle of headlight washer system (4) towards
front from bumper trim.
Installation:
Keep plug connection for high-pressure line (2) and spray nozzle
(4) clean and free from grease.
Make sure high-pressure line (2) is correctly engaged on spray
nozzle (4).
If necessary, top up washer fluid.
Replacement:
Unclip spray nozzle (2) from trim (3).
Installation:
If necessary, replace backing (1).
Guides (5) of backing (1) must be located in openings of spray
nozzle (2).
Catches (4) of trim (3) must not be damaged or missing.
