X Series E83 X3 2.5Si (N52K) OFFRD
5AZ Oil spray nozzles
(6 x)
Oil spray nozzles in crankcase.
N52K
M8 x 1
12 Nm
6AZ Plug
(1 x)
Coolant drain to crankcase.
The end faces of the aluminium
screw heads are painted blue.
N52K
M14 x 1.5
Replace screw and sealing
ring.
Thread repairs are not
permitted!
50 Nm
7AZ Plug
(1 x)
Assembly opening to crankcase.
The end faces of the aluminium
screw heads are painted blue.
N52K
M22 x 1.5
Replace screw.
Thread repairs are not
permitted!
50 Nm
8AZ Plug
(1 x)
Assembly opening to bedplate.
The end faces of the aluminium
screw heads are painted blue.
N52K
M16 x 1.5
Replace screw.
Thread repairs are not
permitted!
27 Nm
AZD Crankcase
