X Series E83 X3 3.0i (M54) OFFRD
Release screws (1) and remove cover (2) from right side of fuel
tank.
Unlock and detach plug (1), fuel feed line (2) and service vent
line (3).
Release screw cap with special tool 16 1 020 and remove
service cap.
Installation:
Tightening torque 16 14 2AZ
.
Installation:
Service cap can only be installed in one position.
When installing, make sure lug (1) of service cap engages in
corresponding opening (2) on fuel tank.
During torque tightening, notch (3) on screw cap can be clearly
heard and felt to engage toothed segment (4) on fuel tank.
Replace rubber gasket.
RA Removing and installing or replacing fuel pump (petrol/gasoline)
