X Series E83 X3 3.0i (M54) OFFRD
8.
Pour coolant into coolant expansion tank up to max. cold fill
level. Marking (2) is then on a level with upper edge of
coolant expansion tank.
9.
Close coolant expansion tank
10. Allow engine to warm up until thermostat opens
Checking coolant level:
Caution!
Check coolant level at a maximum coolant temperature of 30
°
C.
Note:
If ambient temperature exceeds 30
°
C, allow engine to cool down
at least to ambient temperature.
Open cap carefully.
Fluid level is O.K. when top edge of coolant expansion tank is
between both markings (1 and 2) on float needle.
Minimum cold fill level:
•
Upper edge of coolant expansion tank is level with
marking (1).
Maximum cold fill level:
•
Upper edge of coolant expansion tank is level with
marking (2).
If necessary, top up coolant.
Note:
Tank mark indicates the fluid level at approx. 20
°
C.
Check cooling system for leaks.
RA Venting cooling system and checking for leaks (M54 / M56)
