Z Series E85 Z4 2.0i (N46) ROADST
62 11 280
Removing and installing (replacing)
instrument cluster
Note:
Extend steering column completely and set in downward position.
Release screw (1).
Fold back instrument cluster (2) in direction of arrow and pull out
towards rear.
Unlock associated plug connection and disconnect.
Remove instrument cluster (2).
Installation:
Retaining lugs (1) of instrument cluster (2) must be exactly
seated in mountings of instrument panel.
Replacement:
Carry out coding/programming.
Observe following IDC specifications:
•
Programming
•
Coding
•
If necessary, car & key memory
•
CD "CIP"
RA Removing and installing (replacing) instrument cluster
BMW AG - TIS
08.02.2013 15:49
Issue status (12/2007) Valid only until next DVD is issued
