LaCrosse V8-5.3L (2008)
Power Seat Switch: Locations
Passenger Compartment/Roof Component Views
Driver Seat Components 1 of 2
1 - Seat Frame
2 - Seat Lumbar Motor - Driver (AL9)
3 - Heated Seat Element - Driver Back
4 - Heated Seat Element - Driver Cushion
5 - Seat Lumbar Switch - Driver (AL9)
6 - Seat Adjuster Switch - Driver
7 - Heated Seat Relay
8 - Horizontal Motor (part of the Adjuster Assembly)
9 - Front Vertical Motor (part of the Adjuster Assembly)
10 - Rear Vertical Motor (part of the Adjuster Assembly)
11 - Seat Belt Pretensioner - Left
Driver Seat Components 2 of 2
