Regal L4-2.0L Turbo (2011)
16 - Ball Stud
17 - Ignition Coil Bolt
18 - Ignition Coil Bolt Retainer
19 - Ignition Coil
20 - Spark Plug
21 - Camshaft Cover Bolt
22 - Camshaft Cover Bolt Retainer
23 - Oil Fill Cap
24 - Oil Fill Cap Seal
25 - Camshaft Cover
26 - Camshaft Housing Cover Insulator
27 - Camshaft Housing Cover Insulator Bolt
28 - Camshaft Cover Seal
29 - Camshaft Cover Seal
30 - Camshaft Bearing Cap Bolt
31 - Camshaft Bearing Front Cap
32 - Camshaft Bearing Cap
33 - Camshaft Bearing Front Cap
34 - Camshaft Bearing Rear Cap Bolt
35 - Camshaft Bearing Rear Cap - Exhaust
36 - Camshaft Bearing Rear Cap Bolt
37 - Camshaft Bearing Rear Cap - Intake
38 - Power Brake Booster Pump Seal
39 - Power Brake Booster Pump
40 - Power Brake Booster Pump Bolt
41 - Camshaft Position Sensor Bolt
42 - Camshaft Position Sensor
43 - Camshaft Position Sensor O-Ring
44 - Exhaust Camshaft
45 - Intake Camshaft
46 - Roller Finger Follower
47 - Hydraulic Lash Adjuster
48 - Cylinder Head Bolt
49 - Coolant Air Bleed Fitting
50 - Hydraulic Lash Adjuster
51 - Roller Finger Follower
52 - Valve Keys
53 - Valve Stem Seal
54 - Valve Spring
55 - Valve Spring Retainer
56 - Small Cylinder Head Bolt
57 - Cylinder Head
58 - Timing Chain Guide Bolt Access Hole
59 - Exhaust Valve
60 - Intake Valve
61 - Camshaft Position Sensor Bolt
62 - Camshaft Position Sensor - Intake
63 - Camshaft Position Sensor O-Ring
64 - Cylinder Head Gallery Plug
65 - Rear Lift Bracket
66 - Rear Lift Bracket Bolt
67 - Cylinder Head Cover Plate Seal
68 - Cylinder Head Cover Plate
69 - Cylinder Head Cover Plate Bolt
70 - Fuel Injector Hold Down Clamp
71 - Fuel Injector Seal
72 - Fuel Injector
73 - Fuel Injector O-Ring
74 - Fuel Rail
75 - Fuel Rail Pressure Sensor
76 - Fuel Injector Wiring Harness
77 - Fuel Rail Bolt
Timing Chain and Components
