Skylark L4-138 2.3L SOHC VIN 3 MFI QUAD 4 (1992)
Drive Belt: Testing and Inspection
Serpentine Belt Routing
Inspect
^
If fraying of belt is noticed, check to make sure both the belt and tensioner assembly are properly aligned and that the belt edges are not in contact
with the flanges of the generator or compressor pulleys.
^
If a whining noise is heard around tensioner or idler assemblies, check for possible bearing failure.
CAUTION: TO avoid personal injury when rotating the serpentine belt tensioner, use a tight fitting 13 mm wrench that is at least 61 cm
(24") long.
^
Remove or install the serpentine drive belt by rotating tensioner as shown in the illustration.
^
The operation can be done using J 37059.
