Skylark L4-138 2.3L SOHC VIN 3 MFI QUAD 4 (1992)
Engine Mount: All Technical Service Bulletins
Engine Mount Strut - Torque Specifications Revised
Bulletin: 93-6-8
Date: Jan. '93
Ref. No.: 93-86-6
Corp. Ref. No.: 236117
SUBJECT:
SERVICE MANUAL UPDATE - TORQUE SPECIFICATION REVISION
(NEW ARTWORK) FOR LOWER ENGINE MOUNT STRUT
MODELS AFFECTED:
1992-93 SKYLARKS WITH 2.3L (VIN 3-RPO L40)
This is a service manual update to Sections 6A6 and 6A7.
The torque specification for the lower engine mount strut has been revised. Refer to the artwork on the following pages:
1992 Skylark,
Page 6A6-10, Figure 11 - Update with Figure 1
Page 6A7-11, Figure 12 - Update with Figure 1
1993 Skylark,
Page 6A7-11, Figure 12 - Update with Figure 1.
