Seville V8-4.9L VIN B (1995)
Wiper Motor: Service and Repair
1. Disconnect battery ground cable.
2. Remove wiper arm assemblies, then air conditioning pipe shroud.
3. Remove shroud air inlet grille panel.
4. Disconnect electrical connectors from wiper motor.
5. Disconnect wiper transmission drive link socket from wiper motor crank arm using tool No. J 39232, or equivalent.
6. Remove air conditioning shroud pipe from wheel house.
7. Remove three screws, then the wiper motor.
8. Reverse procedure to install.
