Beretta L4-138 2.3L DOHC QUAD 4 HO MFI VIN A (1994)
Powertrain Management
Computers and Control Systems
Relays and Modules - Computers and Control Systems
Engine Control Module / Component Information
Testing and Inspection / Pinout Values and Diagnostic Parameters
Page 3024
Page 3
ECM Connector: C3
ECM Connector: C3
Powertrain Management
Computers and Control Systems
Relays and Modules - Computers and Control Systems
Engine Control Module / Component Information
Testing and Inspection / Pinout Values and Diagnostic Parameters
Page 3024
