Colorado 4WD L5-3.7L (2007)
12. Remove the 3 generator mounting bolts.
13. Remove the engine lift bracket, in order to gain clearance to remove the generator.
14. Position the A/C compressor forward, in order to gain clearance to remove the generator.
15. Remove the generator from the engine.
Installation Procedure
1. Position the generator to the engine.
2. Install the engine lift bracket.
Notice: Refer to Fastener Notice.
3. Install the generator mounting bolts.
Tighten the bolts in sequence to 50 N.m (37 lb ft).
