Malibu V6-3.1L VIN J (2002)
Brake Bleeding: Specifications
ABS Modulator Bleeder Valves
80 inch lbs.
Brake Caliper Bleeder Valve Front
115 inch lbs.
Brake Caliper Bleeder Valve Rear
115 inch lbs.
Brake Rear Wheel Cylinder Bleeder Valve
62 inch lbs.
TCS Modulator Bleeder Valves
80 inch lbs.
Brake System Flushing
Brake Fluid Volume from the Abs Modulator Bleeder Valves
4 oz.
Brake Fluid Volume from the Brake Calipers
8 oz.
Brake System Pressure Bleed
Initial Pressure Adjustment Setting Leak Testing the Hydraulic Brake System
10 psi
Pressure Bleed Procedure Setting
35 psi
