Malibu V6-3.5L VIN 8 (2004)
Coolant Reservoir: Service and Repair
Surge Tank Replacement
Surge Tank Replacement
^
Tools Required
-
J 38185 Hose Clamp Pliers
Removal Procedure
1. Drain the coolant.
2. Reposition the surge tank inlet hose clamp at the surge tank using the J 38185.
3. Remove the surge tank inlet hose from the surge tank.
4. Flex the surge tank mounting tabs outward to release the surge tank from the bracket.
5. Disconnect the coolant level sensor wire harness connector.
