Silverado 1500 2WD V6-4.3L (2007)
minutes.
After the system restarts, press the "EJECT" soft key to eject and remove the software update disc.
Dealers should retain the software update disc for their use.
Load the map DVD into the same slot located behind the display screen, DO NOT put in the top slot.
Press the "CLOSE" soft key.
Press the "OK" soft key.
Press the "MENU" hard key.
The clock will not be displayed until it is confirmed by completing step 16.
Turn the engine OFF, open and close the drivers door. Wait for 10 minutes.
Due to the load time of the system, there may be a short delay before the "Map Screen" appears.
Restart the engine. After the map screen is displayed, verify that the clock is visible and touch the map screen to confirm that it can be scrolled. If the
clock does not appear, repeat programming.
The GPS location will start out in Washington DC and once learned, will show the correct location of the vehicle. Learning the GPS may take up to 10
minutes, depending on the vehicle's location.
Ensure that the GPS signal has been received and the navigation map shows the correct location for the vehicle.
Verify that the destination search area is properly displayed.
Press the "DESTINATION" hard key.
Press "CHANGE SEARCH AREA" soft key.
Select the correct area for the vehicle's location.
Warranty Information
For vehicles repaired under warranty, use the table.
Disclaimer
