Tracker 2WD L4-1.6L VIN 6 (2000)
Center Mounted Brake Lamp Bulb: Service and Repair
2-Door
REMOVAL PROCEDURE
1. Open the rear door.
2. Remove the 2 screws (1) which secure the high mounted stoplamp (2).
3. Pull the stoplamp (3) from the high mounted stoplamp housing (1).
4. Remove the stoplamp bulb socket (2) from the stoplamp (3).
5. Remove the bulb from the socket (2).
INSTALLATION PROCEDURE
1. Install the bulb to the socket (2).
2. Install the high mounted stoplamp bulb socket (2) to the stoplamp (3).
