TrailBlazer 4WD L6-4.2L VIN S (2002)
Air Dam: Service and Repair
Air Deflector Replacement - Front Bumper Fascia
Air Deflector Replacement - Front Bumper Fascia
Removal Procedure
1. Release the tabs that retain the air deflector to the fascia.
2. Remove the push-pin retaining the air deflector to the fascia.
3. Remove the air deflector from the fascia.
Installation Procedure
1. Install the air deflector to the fascia.
2. Install the push-pin that retains the air deflector to the fascia.
3. Install and fully seat the tabs that retain the air deflector to the fascia.
