Crossfire SRT-6 V6-3.2L SC VIN N (2005)
5. Disconnect the clutch master cylinder pressure line (1) at the clutch master cylinder and cap the line.
6. Remove the clutch pedal spring (3), circlip (1), and retaining nuts (2).
7. Rotate the clutch master cylinder counter-clockwise and remove from the vehicle.
INSTALLATION
WARNING: RISK OF POISONING DUE TO SWALLOWING BRAKE FLUID. RISK OF INJURY DUE TO BRAKE FLUID COMING
INTO CONTACT WITH THE SKIN AND EYES.
Note: Only pour brake fluid into suitable, appropriately marked containers. Wear protective clothing and safety glasses when handling brake fluid.
1. Position the clutch master cylinder on the pedal and pivot it clockwise.
2. Install the retaining nuts (2) on the bracket assembly. Tighten nuts to 10 Nm (89 inch lbs.).
3. Install the circlip (1) at the pedal stud.
4. Install the spring (3) to the pedal.
