Crossfire SRT-6 V6-3.2L SC VIN N (2005)
The window opening fence should be cleaned of old urethane bonding material (1).
Refer to the Windshield Removal procedure for a description of tools, cleaning procedures, and adhesive systems that are recommended for use in
this procedure.
1. Clean inside of glass (2) with Mopar Glass Cleaner and lint-free cloth.
2. Apply clear glass primer 25 mm (1 in.) wide around edge of glass (2). Wipe with clean/dry lint-free cloth.
NOTE: Insure primer does not flow passed the black frit.
3. Apply black primer 25 mm (1 in.) wide around edge of glass (2). Allow at least eighteen minutes drying time.
4. Apply a 12 mm (0.5 in.) high by 8 mm (0.3 in.) wide triangular bead of urethane (3) around window edge.
5. Position the glass (2) into the window opening, install screws (4) and (5).
6. After urethane has cured, water test quarter window to verify repair.
