Sebring Convertible V6-2.5L VIN H (1997)

Page 2
background image

When the PCM energizes the ASD and fuel pump relays, terminal 87 connects to terminal 30. This is the On position. Terminal 87 supplies
voltage to the rest of the circuit.
