Page 4
background image

13. Install the spring washer, hub nut lock, and new cotter pin. Wrap cotter pin prongs tightly around the hub nut lock.
14. Install front wheel and tire assembly. Install front wheel lug nuts and tighten in correct sequence. Then tighten to a torque of 135 Nm (100 ft lbs).
15. Lower vehicle.
16. Set front Toe on vehicle to required specification. Use procedure listed under Alignment.
