Air Door Actuator / Motor: Testing and Inspection
Actuator Calibration/Diagnostics and Cool Down Test
GENERAL INFORMATION
If the HVAC control module is replaced, the Calibration Diagnostic and Cool-down tests will need to be performed. Once this group of tests have
successfully passed, they can be performed individually. The engine must be running during the test to provide hot coolant for the heater, A/C
compressor operation and to assure that the actuators are calibrated correctly The HVAC control module is capable of troubleshooting the system
in approximately 120 seconds. If a condition is detected, an error code is displayed. The error code cannot be erased until the condition is repaired
and the diagnostic test is performed. Check wire before replacing components.
CAUTION: Do not remove the actuators from the Heater-A/C unit assembly with power applied. Removal should only be done with the Ignition
OFF. The actuators have no mechanical stops to limit the travel. If the actuator rotates and is not connected to the unit assembly, it will become out
of calibration.
ACTUATOR CALIBRATION
Radio Bezel And HVAC Control
Radio Bezel And HVAC Control, Rear Blower Motor Switch And Zone Control
Mode, Blend and Zone (if equipped) door calibration compensates for mechanical variations in the actuators, HVAC control module and its
linkages. In vehicle calibration can be entered from the control's front panel. If the REAR WIPE and INTERMITTENT LED's flash
simultaneously when Ignition is cycled ON, the actuators have not been calibrated or during the previous calibration a failure occurred.
Diagnostics will always occur during Calibration Diagnostic and Cool-down test.
DIAGNOSTICS
During the Actuator calibration, diagnostics are performed on the actuators and evaporator temperature Fin Sensor. Once diagnostics are
completed the REAR WIPER and INTERMITTENT LED's will flash to indicate either a successful calibration or the appropriate fail code(s). At
this time manual testing of the Blend, Mode and Driver (if equipped) potentiometers can be performed. If a failure is detected during Diagnostics a
fault will be set in the control. When Ignition is cycled OFF and then ON or Diagnostics is aborted, the REAR WIPER and INTERMITTENT
LED's will flash simultaneously showing that a failure has occurred. The control will not indicate the fail code, but only that a failure had occurred
during the last diagnostics test. The only way to clear the failure codes is repeat the Calibration Diagnostic and Cool-down test, after all repairs are
