Voyager L4-2.4L VIN B (2001)
Power Window Switch: Service and Repair
REMOVAL
1. Disconnect and isolate the battery negative cable.
Fig.4 Power Window Switch
2. Using a trim stick, start at the bottom of the switch and bezel assembly and pry up to remove the switch and bezel assembly from the door trim
panel.
3. Unlatch the locking tab on the harness side connector of the switch.
4. Disconnect wire harness connectors from switch.
INSTALLATION
1. Reconnect wire harness connector to switch.
2. Insert switch into door trim panel and press into place.
3. Reconnect battery negative cable.
