Voyager L4-2.4L VIN B (2001)
7.
Disconnect crossover cable from transaxle crossover lever (Fig. 1).
8.
Disconnect selector cable from transaxle selector lever (Fig. 1).
9.
Using a 5.0 mm (0.196 in.) pin punch, remove the double roll pin from the selector lever.
10.
Remove the lever from the shaft.
11.
Place the new selector lever (p/n 05104812AA) on the shaft in the same orientation that the old lever was removed, being careful to line up the
hole in the lever and shaft.
12.
Install the double roll pin as follows:
a.
Start the large roll pin into the lever just far enough to engage the shaft.
b.
Start the small roll pin into the large roll pin.
c.
Finish driving both roll pins into the lever until they are both flush with the lever.
13.
Install the selector cable onto the transaxle selector lever.
14.
Install the crossover cable onto the transaxle crossover lever.
15.
Verify the shifter is operating properly.
16.
2.4L gas vehicles go to step 21. 2.5L Turbo Diesel vehicles, install the coolant recovery bottle mounting bracket.
17.
Install the coolant recovery bottle in the bracket.
18.
Connect battery temperature sensor. Install battery tray.
19.
Install battery, clamp and hold down nut.
20.
Install battery thermal shield.
