Leganza CDX L4-2.2L DOHC D-TEC MFI (1999)
Brake Pedal Assy: Service and Repair
Removal Procedure
1. Remove the screws that hold the trim panel to the instrument panel.
2. Remove the trim panel.
3. Remove the driver's side knee bolster.
4. Remove the stoplamp switch.
5. Disconnect the spring retaining clip and the bolt from the pushrod clevis.
6. Remove the hex nut and the spring.
7. Remove the brake pedal and the bolt.
