Caravan L4-2.4L VIN B (2003)
Drive Belt: Adjustments
Accessory Drive Belt Tension Chart
ADJUSTMENTS
Satisfactory performance of the belt driven accessories depends on proper belt tension. Belt tensioning should be performed with the aid of Special
Tool 7198. Because of space limitations in the engine compartment, the use of this gauge may be restricted. Raise the vehicle on a hoist and the
remove the splash shield to gain access to the drive belts, if necessary. Adjust belt tension for either a New or Used belt.
