Caravan FWD V6-3.3L VIN 3 Flex Fuel (2001)
Front Door Window Glass Weatherstrip: Service and Repair
Front Door Outer Belt Molding
FRONT DOOR OUTER BELT MOLDING
REMOVAL
1. Remove the side view mirror.
2. Remove door trim panel.
3. Roll door glass down.
Fig. 1
4. Using a hook tool, disengage interlocking lip at the base of the inward edge of the belt molding (Fig. 1).
5. Remove belt molding from door.
INSTALLATION
1. Place belt molding in position on door (Fig. 1).
NOTE: Make sure end of applique is against outer belt.
2. Engage interlocking lip at the base of the inward edge of the belt molding on door panel.
3. Install door trim panel.
