Challenger V6-3.5L (2009)
14. Position the bulkhead insulator aside to gain access to the battery positive cable bulkhead fastener.
15. Remove the battery positive cable to bulkhead fastener.
16. Remove the battery positive cable from the vehicle making note of the cable routing under the floor cross members.
POSITIVE - ENGINE COMPARTMENT
1. Turn the ignition switch to the Off position. Be certain that all electrical accessories are turned off.
2. Remove the spare tire cover to gain access to the battery.
3. Disconnect and isolate the battery negative cable (3).
4. Raise vehicle on hoist See: Maintenance/Vehicle Lifting/Service and Repair.
5. Remove the right front wheelhouse splash shield to gain access to the battery positive cable bulkhead outside terminal See: Body and
Frame/Fender/Front Fender/Front Fender Liner/Service and Repair/Splash Shield - Removal.
