Grand Caravan V6-3.8L (2009)
ABS Light: Description and Operation
ABS Indicator - Description
DESCRIPTION
An Antilock Brake System (ABS) indicator is standard equipment on all instrument clusters. On Dodge vehicles, this indicator is located near the bottom
of the speedometer dial face of the cluster overlay, near the center. On Chrysler vehicles, this indicator is located near the top of the cluster overlay,
between the speedometer and the tachometer.
The ABS indicator consists of a stencil-like cutout of the International Control and Display Symbol icon for Failure of Anti-lock Braking System in
the opaque layer of the instrument cluster overlay. The dark outer layer of the overlay prevents the indicator from being clearly visible when it is not
illuminated. An amber Light Emitting Diode (LED) behind the cutout in the opaque layer of the overlay causes the indicator to appear in amber through
the translucent outer layer of the overlay when it is illuminated from behind by the LED, which is soldered onto the instrument cluster electronic circuit
board.
The ABS indicator is serviced as a unit with the instrument cluster.
