Grand Caravan AWD V6-3.8L VIN L (2001)
Engine Oil Pressure: Specifications
OIL PRESSURE
@ Curb Idle Speed
5 psi
(at normal operating temperature)
If pressure is ZERO at curb idle, DO NOT run engine at 3000
rpm.
@ 3000 rpm
30 - 80 psi
Oil Filter Bypass Valve Setting
9 - 15 psi
Oil Pressure Switch Actuating Pressure
2 - 4 psi
