Grand Caravan AWD V6-3.8L VIN L (2001)
Exhaust Manifold: Service and Repair
Exhaust Manifold - Right
EXHAUST MANIFOLD - RIGHT
REMOVAL
1. Disconnect battery negative cable.
2. Remove the wiper module.
3. Disconnect spark plug wires.
4. Remove bolts fastening crossover pipe to exhaust manifold.
5. Disconnect and remove the upstream oxygen sensor.
6. Remove the heat shield attaching screws.
7. Remove the upper heat shield.
8. Raise vehicle on hoist and remove drive belt shield.
