Grand Caravan AWD V6-3.8L VIN L (2001)
Output Shaft: Service and Repair
TRANSFER SYSTEM OUTPUT SHAFT/GEAR/BEARING
REMOVAL
NOTE: Transfer Gear should be removed for repair of output shaft, to obtain an accurate output shaft turning torque measurement upon reassembly.
NOTE: Transaxle geartrain must be removed to gain access to and service output shaft.
1. Using a suitable punch, bend retaining strap tabs flat to facilitate bolt removal (Fig. 238).
2. Remove retaining strap and stirrup-to-gear bolts (Fig. 239).
