Magnum V8-5.7L (2008)
Global Positioning System Antenna: Diagrams
Component ID:
14
Component :
ANTENNA-GLOBAL POSITIONING SYSTEM
Connector:
Name :
ANTENNA-GLOBAL POSITIONING SYSTEM
Color :
GRAY
# of pins :
2
Qualifier :
(NAVIGATION)
Pin
Circuit
Description
1
D8 WT/LB
GPS ANTENNA SIGNAL
2
D108 LB/WT
GPS ANTENNA SHIELD
