Nitro 2WD V6-4.0L (2007)
Towing Hook / Bracket: Service and Repair
Hook - Front Tow
Removal
REMOVAL
1. Remove the jounce bumper spacer.
2. Remove the tow hook (4) from the eye assembly (6).
3. Remove the bolts (5) from the eye assembly (6).
4. Remove the nuts (7) from the eye assembly (6).
5. Remove the eye assembly (6) from the front bumper crossmember (1).
6. Remove the stud plate (2) and body fasteners (3) from the front bumper crossmember (1).
Installation
INSTALLATION
1. Install the stud plate (2) and body fasteners (3) to the front bumper crossmember (1).
2. Install the eye assembly (6) to the front bumper crossmember (1).
3. Install the nuts (7) and bolts (5) to the eye assembly (6) and tighten to 61 Nm (45 ft. lbs.).
