RAM 1500 Truck 2WD V8-5.2L VIN Y (1997)
Carrier Bearings: Service and Repair
Rear Axle - 286RBI
REMOVAL
1. Remove differential case from axle housing.
2. Remove the bearings from the differential case with Press 938 and Bearing Splitter 1130, or equivalents.
NOTE: If ring and pinion gears have been replaced, verify differential side bearing preload and gear mesh backlash.
INSTALLATION
1. Using tool C-4190 with handle C-4171, or equivalents, install differential side bearings.
2. Install differential in axle housing.
