RAM 3500 Truck 2WD L6-5.9L DSL Turbo VIN 6 (1999)
Injector Clamp Removal/Installation
a. Remove the injector clamp from the cylinder(s) to be serviced. Do not remove the bolt shown.
Spring Compressor Mounting Base-Part Of Tool 8319
b. Install the valve spring compressor mounting base as shown. Reinstall lube injector clamp bolt finger tight.
Compressing Valve Springs With Tool 8319
c. Install the top plate, washer, and nut. Using a suitable wrench tighten the nut (clock-wise)to compress the valve springs and remove the collets.
d. Rotate the compressor nut counter-clockwise to relieve tension on springs. Remove spring compressor.
e. Remove and replace retainers, springs, and seals as necessary.
