RAM 3500 Truck 4WD V10-8.0L VIN W HDC (1999)
Figure 4
13.
Place water shield into the speaker opening as shown in Figure 4.
14.
Position the new speaker into the door opening with the amplifier facing up. Secure the speaker with the four screws.
15.
Route the speaker wiring from underneath the speaker, along the side of the speaker and up to the connector as shown in Figure 4.
Figure 5
16.
Peel the protective backing from the foam (from Foam Kit p/n 05018968AA) and place the foam onto the inner door panel trim as shown in Figure
5.
17.
Remove all door trim panel retaining clips
18.
Install new door trim panel retaining clips pin 06505878AA onto the door trim panel.
