Sprinter 3500 V6-3.0L DSL Turbo VIN 45 (2007)
Blower Motor Resistor: Diagrams
Component ID:
305
Component :
REGULATOR-BLOWER MOTOR
Connector:
Name :
REGULATOR-BLOWER MOTOR
Color :
# of pins :
4
Qualifier :
(ATC)
Pin
Description
Circuit
1
GROUND
10BR
2
-
20GY
3
BLOWER MOTOR CONTROL
10BR
4
FUSED B(+)
U162 10RD/WT
