Sprinter 3500 V6-3.0L DSL Turbo VIN 45 (2007)
Compressor Clutch: Diagrams
Clutch-A/C Compressor
Component ID:
101
Component :
CLUTCH-A/C COMPRESSOR
Connector:
Name :
CLUTCH-A/C COMPRESSOR
Color :
# of pins :
1
Pin
Description
Circuit
1
COMPRESSOR CONTROL VALVE
4813 18DB/DG
Pin
Description
Circuit
1
COMPRESSOR CONTROL VALVE
3913 18DB/DG
