Sprinter 3500 V6-3.0L DSL Turbo VIN 45 (2007)
Control Assembly: Connector Views
Control-A/C-Heater
Component ID:
115
Component :
CONTROL-A/C-HEATER
Connector:
Name :
CONTROL-A/C-HEATER C1
Color :
# of pins :
6
Pin
Description
Circuit
1
FUSED B(+)
491 10RD
2
-
U151 10WT
3
-
487 10DG
4
-
488 10DB
5
-
2325 10BR
6
-
U162 10RD/WT
Connector:
Name :
CONTROL-A/C-HEATER C2
Color :
BLACK
# of pins :
28
