Summit L4-1795cc 1.8L SOHC (1995)
Shift Valves
11.. Remove rear end cover, and then remove 1-2 shift valve and 2-3 shift plug.
Upper Valve Body
12. Remove front end cover and plate, and then remove springs, valves and filter from upper valve body.
13. Remove the end cover, and then the clutch control valve accumulator valve, plug, reducing valve and springs.
REASSEMBLY
CAUTION: Clean all parts with ATF. Do not use shop towels during reassembly operation. Tighten all valve body screws to 4 - 5.5 Nm (3 - 4
ft.lbs.). Using torque set driver, etc., torque all screws evenly.
