Contour V6-153 2.5L DOHC (1996)
3. Remove and discard caliper piston dust seal and piston seal.
4. Remove bleeder screw, then locating pin, pin dust seals and bushings.
5. Cut tie-wrap, then remove cover and dust seals from parking brake actuator.
6. Mount caliper in a suitable vise with soft jaws, positioned to access parking brake actuator.
7. Compress actuator spring, then remove parking brake actuator arm and cam.
8. Remove cup washer and adjuster springs from adjuster spindle, note position of components for later assembly.
9. Remove adjuster spindle and seal from caliper, then remove seal from spindle.
CLEANING & INSPECTION
1. Clean all metal components with isopropyl alcohol.
2. Use compressed air to clean out passages and grooves.
