Contour V6-153 2.5L DOHC (1996)
Air Door Actuator / Motor: Service and Repair
Blend Door Motor
REMOVAL
1. Remove two lower retaining screws from A/C electronic door actuator motor.
2. Open glove compartment, push in on sides of glove compartment to bypass stops and lower door to floor.
3. Disconnect wire harness connector from A/C electronic door actuator motor.
4. Remove two upper retaining screws and A/C electronic door actuator motor from A/C evaporator housing.
INSTALLATION
1. To install, reverse Removal procedure.
