Contour V6-153 2.5L DOHC (1996)
Driven Sprocket Bearing Removal
a. Install threaded drawbar tool No. T75T-1176-A, servo plug replacer/needle bearing receiver tool No. T94P-77000-E2, and needle bearing
replacer tool No. T94P-77000-E1, or equivalents.
b. Rotate drawbar tool until bearing seats in case.
ASSEMBLE
1. If driven sprocket bearing has been removed from transaxle case, install as follows:
a. Install threaded drawbar tool No. T75T-1176-A, servo plug replacer/needle bearing receiver tool No. T94P-77000-E2, and needle bearing
replacer tool No. T94P-77000-E1 or equivalents, as shown in the Driven Sprocket Bearing Removal Tool Installation image and the Driven
Sprocket Bearing Removal image.
b. Rotate drawbar tool until bearing seats in case.
2. Install oil tube connector and line pressure port plug on transaxle case and tighten.
3. Seat manual control seal in transaxle case using a small rubber mallet, then install manual valve detent lever assembly and shaft.
4. Using a hammer and punch, install retaining pins for manual shaft and manual valve detent lever shaft, then verify that manual valve detent lever
assembly rotates freely.
5. Install manual valve Z-link, then the parking brake pawl and park pawl return spring.
6. Install park pawl shaft, retainer and bolt. Tighten bolt.
7. Install manual control lever seal using throttle shaft seal replacer tool No. T81P-70337-A or equivalent, then assemble park pawl actuating cam,
cam actuator, and park lever spacer on manual control shaft as shown in the Manual Control Lever Shaft And Park Pawl Assembly image.
8. Install manual control lever shaft assembly and nut in transaxle case. Tighten nut.
9. Install park pawl ratcheting spring, manual control lever assembly, and bolt. Leave bolt finger tight until linkage is adjusted.
10. Using rear lube tube seal replacer tool No. T91P-76085-A or equivalent, install final drive lube tube seal in transaxle case, then push tube into
seal.
Lube Tube Installation
11. Push final drive lube tube into bearing of transaxle case. Seat with lube tube replacer tool No. T94P-77000-U2 or equivalent.
