E 250 V10-6.8L VIN S (2005)

Page 2
background image

5. Remove the stud bolts and position the heater outlet tube aside.

6. Remove the two transmission-to-engine bolts.

7. Disconnect the oil fill tube from the RH valve cover.

8. Remove the bolt and the oil fill tube.
