E 250 V10-6.8L VIN S (2005)
Transmission Position Switch/Sensor: Service and Repair
4R70W/4R75W
Digital Transmission Range (TR) Sensor
Special Tool(s)
Removal
1. With the vehicle in NEUTRAL, position it on a hoist.
2. Disconnect the digital TR electrical connector.
3. Disconnect the shift cable end.
4. Remove the manual control lever.
1. Remove the manual control lever nut.
2. Remove the manual control lever.
5. Remove the digital TR sensor.
1. Remove the two retaining bolts.
