E 250 V8-4.6L SOHC VIN W (2004)
10. NOTE: Passenger seat shown.
Position the inboard side shield.
1
Position the inboard side shield to the safety belt buckle and pretensioner boot and engage the retaining clips.
2
Install the pin-type retainer.
3
Position and align the inboard side shield to the seat.
11. NOTE: Passenger seat shown.
Rotate the inboard side shield downward to engage the front and center upper hooks.
12. NOTE: Passenger seat shown.
Install the inboard side shield screws from underneath the seat.
All vehicles
13. WARNING: To reduce the risk of serious personal injury, read and follow all warnings, cautions, notes, and instructions in the seat
removal and installation procedure.
Install the seat with the affected safety belt buckle pretensioner.
14. WARNING: To reduce the risk of serious personal injury, read and follow all warnings, notes, and instructions in the supplemental
restraint system (SRS) deactivation/reactivation procedure.
Reactivate the supplemental restraint system (SRS).
