E 250 V8-4.6L VIN W (2006)
Shift Solenoid: Service and Repair
Solenoid Body Assembly
Solenoid Body Assembly
Special Tool(s)
Material
Removal
1. Remove the transmission fluid pan, gasket and filter.
2. Disconnect the solenoid body electrical connector.
